Overview and Applications
AWG 22 instrumentation cables are ideal for low-level signal transmission over medium distances. Their moderate conductor size makes them suitable for space-constrained environments while still providing reliable performance in industrial settings. These cables are commonly used in automation and process control systems requiring precise data transmission with low current requirements.
Typical Applications:
- RTD and thermocouple extension wiring
- Low-voltage digital communication (e.g., Modbus, RS-485)
- SCADA systems and process automation
- Data acquisition systems (DAQ)
- Wiring inside terminal blocks and compact control panels
Conductor Resistance (Ohm/KM)
Maximum Voltage (V)
Shield
Jacket Thickness (mm)
Conductor Material
Conductor
Cable Diameter (mm)
Number of Conductors
Suitable Applications
Cable Type & Size
5.5
2
22×2×1
6
4
22×2×2
6.5
6
22×2×3
7
8
22×2×4
8
10
22×2×5
8
12
22×2×6
8.5
14
22×2×7
8.5
16
22×2×8
9.5
18
22×2×9
9.5
20
22×2×10
10
22
22×2×11
10.5
24
22×2×12
5
2
22×2
58
300
Tinned copper (70% coverage)
1
Tinned copper
0.160×19
5
3
Compact Instrumentation Systems
22×3
5.5
4
22×4
6
5
22×5
6
6
22×6
6
7
22×7
6.5
8
22×8
7
9
22×9
7.5
10
22×10
7.5
11
22×11
7.5
12
22×12
8
13
22×13
8
14
22×14
8.5
15
22×15
**Options:** PVC jacket is standard. LSZH jackets and foil shielding are available upon request.
