Nominal Attenuation (dB/100 ft)
Attenuation(dB/100m)
Frequency (MHz)
2.51
5
7.1
50
9.1
100
13.5
230
18
400
26
800
27.5
862
29.8
1000
35
1350
40.2
1750
46.2
2150
49
2400
56.1
3000
62.9
3600
69.2
4200
75.2
4800
81
5400
86.5
6000
Mechanical Characteristics
Value
Parameter
30°C to +70°C-
Operating Temperature
5°C to +50°C-
Installation Temperature
30°C to +70°C-
Storage Temperature
100N (22 lbf)
Max Pull Tension
Electrical Characteristics
Value
Parameter
15.4Ohm/km (4.69 Ohm/1000 ft)
Max. Conductor DCR
50Ohm
Characteristic Impedance
80%
Velocity of Propagation
Applications
- Point-to-point and point-to-multipoint wireless
antenna communication - Wireless microphones
- Two-Way Radios
- Amateur (Ham) Radio
- Low Power FM
- GPS
- RFID (Radio Frequency Identification)
Standards & Compliance
- Environmental Suitability: Indoor – Euroclass Dca
- Flammability / Reaction to Fire: IEC 60332-1-2, UN ECE R118.03
- CPR Compliance: CPR Euroclass: Dca-s1,d1,a1; CPR UKCA Class: Dca-s1,d1,a1
- CENELEC Compliance: EN 50117-1, EN 50117-9-2, EN 50290-2-20
- European Halogen Free Standards: EU CE Mark
- UK Regulation Compliance: UKCA Mark
